Tree Breadth First Search: Pattern for Coding Interviews

This pattern is based on the Breadth First Search (BFS) technique to traverse a tree or tree-like data structures.

Any problem involving the traversal of a tree in a level-by-level order can be efficiently solved using this approach. We will use a Queue to keep track of all the nodes of a level before we jump onto the next level.

Question asked at FAANG interviews: Binary Tree Level Order Traversal

Problem Statement : Given a binary tree, populate an array to represent its level-by-level traversal. You should populate the values of all nodes of each level from left to right in separate sub-arrays.

Hers’s an example below:

Level order Traversal in Tree

Try to brainstorm and implement the algorithm yourself before jumping to the solution below.

Solution

Since we need to traverse all nodes of each level before moving onto the next level, we can use the Breadth First Search (BFS) technique to solve this problem.

We can use a Queue to efficiently traverse in BFS fashion. Here are the steps of our algorithm:

  1. Start by pushing the root node to the queue.
  2. Keep iterating until the queue is empty.
  3. In each iteration, first count the elements in the queue (let’s call it levelSize). We will have these many nodes in the current level.
  4. Next, remove levelSize nodes from the queue and push their values in an array to represent the current level.
  5. After removing each node from the queue, insert both of its children(if exist) into the queue.
  6. If the queue is not empty, repeat from step 3 for the next level.

Let’s take the example mentioned above to visually represent our algorithm:

Start by pushing the root to the queue
Count the elements of the queue (levelSize = 1), they all will be in the first level. Since the levelSize is “1” there will be one element in the first level.
Move “one” element to the the output array representing the first level and push its children to the queue.
Count the elements of the queue (levelSize = 2), they all will be in the second level. Since the levelSize is “2” there will be two elements in the second level.
Move “two” elements to the the output array representing the second level and push their children to the queue in the same order.
Count the elements of the queue (levelSize = 3), they all will be in the third level. Since the levelSize is “3” there will be three elements in the third level.
Move “three” elements to the the output array representing third level.

Code(JavaScript)

const Deque = require('./collections/deque'); class TreeNode {         // a typical tree node structureconstructor(val) {this.val = val;this.left = null;this.right = null;}}
function bfsTraverse(root) {result = []; // stores the final resultif (root === null) {return result;}const queue = new Deque();queue.push(root); // add the root node initiallywhile (queue.length > 0) {const levelSize = queue.length; currentLevel = [];for (i = 0; i < levelSize; i++) {currentNode = queue.shift();
// add the node to the current levelcurrentLevel.push(currentNode.val);
// insert the children of current node in the queueif (currentNode.left !== null) {queue.push(currentNode.left);}if (currentNode.right !== null) {queue.push(currentNode.right);}}result.push(currentLevel);}return result;}

Time complexity of the above algorithm is O(N), where ’N’ is the total number of nodes in the tree. This is due to the fact that we traverse each node once.

Space complexity of the above algorithm will be O(N) as we need to return a list containing the level order traversal. We will also need O(N) space for the queue. Since we can have a maximum of N/2 nodes at any level (this could happen only at the lowest level), therefore we will need O(N) space to store them in the queue.

That’s all about Pattern — Breadth First Search. Will discuss more coding problems in the upcoming stories.
